This is V1, this is still very much a work in progress
IMPORTANT STUFF:
Design Issues:
Mask has no clearance and literally has to be hammered into place.
The left side of the mask sinks too low into the face.
The permanent "Tooth support" is currently 1.5mm wide, and should be widened to 3.5mm for better support, the mouth has already been updated to compensate.
Official art by Nintendo shows an outline around Castform's face (between the mask and the face), this is currently the only part of Castform's design left out of this model.
The file for the reflection off of the Eyes is incorrectly named "Pupils."
What You Should Print:
Body - Light Gray - x1 (this is the only part where supports are needed)
Mask - White - x1
Eyes - Black - x2
Mouth - Black - x1 (recommended print, but it'll still look fine if you decide not to print this part)
Pupils - White - x2 (NOT recommended, instead, place 1.75mm white PLA in eye sockets, and cut to size, this file is for those wishing to scale the model, or without 1.75mm filament)
LESS IMPORTANT STUFF:
It probably took more time to type out the Design Issues paragraph then it would've to fix most of the problems.
The original model was taken from ChaosCoreTech's design here on Thingiverse.
Don't hesitate to leave a comment if you have any questions/requests regarding this design.
All tips and proceeds are donated to the GreenPanda256 needs more filament fund.
This model is strictly not for commercial use.
Printer Brand:
Creality
Printer:
Ender 3
Rafts:
Doesn't Matter
Supports:
Yes
Resolution:
I recommend .12, V2 will bring better tolerances for lower resolutions
Infill:
10 - 25%
Filament: eSun & Hatchbox PLA Light Gray, White, and Black. I used Silver instead of Light Gray
