by johnmcwGeo

Original Design Speed Racer (Gō Mifune)

Face: I use Sharpie markers.  Use Supports around the lower face. (Flesh)

Helmet -M filled in with Sharpie.  I printed the helmet upside down and used supports. (White).   I then used the SpeedRacerVisor Pattern to cut clear plastic (clear small plastic cups works very well, but here is clear plastic packaging on lots of things)

Arms: start with Blue then White at Layer 77 then switch to flesh at Layer 99.
Putting on the arms I use a little veg oil on the body holes,
the arms will go in with a bit of pressure and rotating.

Collar: IFlipped 180 and use supports under the edge of the V, afterward the V separates from the other part of the collar for easier assembly. (White)

Hair:  I rotated it 130 degrees on Y and used supports. (Black)

Hips: Start with Blue then switch at layer 88 to White.

Legs:  Start with Brown(shoes) at layer 44 switch to Red(socks) at layer 50 switch to White (pants)

Neck:  I flipped 180 degrees and printed with supports on the edges. (Flesh)

Torso:  no supports necessary (Blue)

Hands:  no supports necessary (Orange)

G:  no supports necessary (Yellow)

Scarf: Use Ribbon or Fabric (Red)

Print Settings

Printer Brand:

Creality

Printer:

CR-10S

Rafts:

No

Supports:

Yes

Resolution:

.14mm

Infill:

20%

Notes:

I listed the layers that I change colors at, but the layers are based on .14mm resolution, you will have to adjust if you print at a different resolution.

I use supports on some things and I always use a Skirt/Brim for added adhesion.
